Woolloongabba station construction update - October 2021

This month, it’s all about breakthroughs. The roadheaders have successfully broken through at the Boggo Road station worksite, marking completion of mined tunnel excavation south from Woolloongabba. The Tunnel Boring Machines (TBMs) Else and Merle will breakthrough at the Northern Tunnel Portal later this year, completing bored tunnelling for the project.



Details of work

Tunnelling and station box

The following works are ongoing until late 2021.

The below tunnelling and tunnelling support activities are undertaken 24 hours a day.

  • TBM 1 Else and TBM 2 Merle tunnelling continues from the Roma Street underground station worksite towards the Northern Tunnel Portal at Spring Hill. Both TBMs will breakthrough by the end of the year
  • Cross passage excavation in the TBM tunnels continues in the city and Roma Street area
  • Roadheader excavation and cross passage works are now complete in the mined tunnels
  • Permanent works in the mined tunnels including waterproofing will continue for the remainder of the year
  • Works continue on the station platform and associated structures in the southern cavern
  • Back of house level B7 in the station box has now been poured and another back of house level (B4) will be completed this month
  • The jump form system has completed 8 out of 17 lifts in total to date. Throughout October, the jump form will start to rise out of the station box and be visible to the community
  • Station fit-out works will also start in the basement level and back of house works will start in the southern cavern.



Jump form system on its way up within the station box


Spoil haulage and deliveries

The works will occur within standard construction hours which are 6:30am to 6:30pm, Monday to Saturday.
Some activities will be completed out of normal construction hours, 6.30pm to 6.30am, due to traffic permits, safety requirements and construction methodology. Nearby residents will be notified in advance via letterbox drop.

The tunnelling and tunnelling support activities will be undertaken 24 hours a day.

The below works will be ongoing until late 2021 due to tunnelling activities and will include:

  • Spoil removal from TBM and roadheader excavation continues 24 hours, with spoil conveyed to the acoustic spoil shed where it is stored, ready for transportation*. This work will continue until all tunnelling related activities are complete.
  • Out-of-hours oversized equipment such as precast segments and tunnelling machine deliveries continue in and out of the Woolloongabba site*.

*Please note this excludes peak hours Monday to Friday 7:00am – 9:00am and 4:30pm – 6:30pm.


Surface works

The works will occur within standard construction hours which are 6:30am to 6:30pm, Monday to Saturday. Some activities will be completed out of normal construction hours, 6.30pm to 6.30am, due to traffic permits, safety requirements and construction methodology. Nearby residents will be notified in advance via letterbox drop.

The below works will be ongoing until end of project:

  • Assembly of formwork for the mined tunnels continues
  • Utility, survey and geotechnical works in and around the Woolloongabba site
  • Delivery and mobilisation of large plant and vehicles
  • Demobilisation of the gantry crane.



What to expect

  • Potential noise, dust and vibration from construction activities both underground in the tunnels and on the surface of the site
  • Temporary lighting for out-of-hours works in the station box and decline ramp
  • TBM operation and support including spoil removal via conveyor to the spoil shed
  • Removal of excavated material during approved haulage hours by trucks. Dust suppression is undertaken regularly using a range of methods including water trucks on site
  • 24-hour ongoing underground excavation in the TBM tunnels and for cross passage excavation
  • Continued utility investigations, surveying, geotechnical works and service relocation activities both on and off site
  • Out-of-hours deliveries of large trucks and plant. This may also include mobilisation and set up. Short term road closures in the area may also be required.

Work is subject to relevant approvals and suitable weather conditions
